淺談液壓系統油缸選型參數

液壓油缸是液壓系統的執行元件，那么如何爲液壓站選擇合適的液壓油缸呢？油缸選型參數又有哪些呢？

一、液壓油缸選型要點

1、作業參數：作業壓力、環境溫度、運轉速度

2、裝置方法：油缸固定方法和活塞桿銜接方法

3、油口方法：M、BSPP、Flange、NPT

4、基本參數：缸徑、、桿徑、行程、速度。

5、外形：圓形缸或拉桿式

6、介質：石油基、水-乙二醇、磷酸脂

二、怎么正確運用液壓油缸？

1、選型

基本上，液壓缸是定制化商品

知道而且正確選型非常重要，至少60%的運用疑問源自于不正確的選型

油缸選型關鍵

2、裝置與運用

油液清潔度、運用環境

油缸的放置、防護
