淺談液壓系統空載和負載試車調試

液壓系統空載和負載試車調試，一起來看下吧。

1.液壓系統空載試車：

(1)液壓泵在卸荷狀態下，檢查其卸荷壓力是否在規定的范圍內。

(2)調整液壓系統各壓力控制閥的預定值、變量泵的偏心距或傾角、各阻尼孔開口、保壓或延時時間等項目。檢查各參數的準確性和穩定性。

(3)檢查液壓系統各執行元件是否按預定順序和工作循環動作，各動作是否協調.運動是否平穩。

(4)空載運行后.檢查溫升及各工作部件的精度是否達到要求。

(5)啓動液壓泵，液壓泵啓動前應進行油液升溫。

(6)操縱手柄，使各執行元件逐一空載運行.調整各流量控制閥，使液壓系統液壓系統各執行元件的運動速度由慢到快.行程由小到大.直至快速全程運行以排除液壓系統中的空氣，觀察速度換接的平穩性。

(7)檢查油管接頭處、元件結合面及密封處有無洩漏。

(8)檢查油箱液面是否因油液進入系統而下降太多。

2.液壓系統負載試車：

負載試車采用間斷加載的方式進行。一般包括輕負載、最大工作負載、超負載試車三個階段。運行中仔細觀察運轉狀態并綜合檢查流量、壓力、速度、沖擊、振動、噪聲、平穩性、洩漏、油溫等情況。對金屬切削機床要進行試切削.檢查在規定的切削范圍內能否達到規定的加工精度和表面質量。對高壓液壓泵站要由低到高進行分級試壓.試驗壓力爲工作壓力的2倍或大于壓力劇變的峰值，檢查洩漏和耐壓強度是否合格。調試期間，將測得的各種參數做好記錄.備查。調試完畢后，液壓系統進人正常工作狀態.鎖緊調整部位.再次緊固各固定件。
