液壓系統回油管的安裝

①在液壓系統中油缸或溢流閥的回油管，應伸到油箱油面以下，以防止飛濺引起氣泡，同時回油管應切出朝向油箱壁的45°斜口。

②溢流閥的回油管不能直接和泵的入口連通，一定要通過油箱，否則油溫將上升得很快。

③油缸具有外洩漏的減壓閥、順序閥、電磁閥等元件的洩漏油管與回油管連通時，不得有背壓，否則應將洩油口單獨接回油箱，以免影響閥的正常工作，如圖1所示。

有些液壓元件帶有外洩漏油接口，如柱塞泵、擺線馬達、電磁閥等的漏油口與回油管相通時，不能存在有背壓，這些洩漏油通常要求直接引回油箱。如果與回油管連通而間接回油，回油管一定不得有背壓，因爲如果有一定的背壓可能造成元件密封的損壞。

④進出油箱管路應密封良好。在油箱上的進出油箱管路應進行有效密封，以免灰塵、水汽通過間隙進入油箱，使油液變質，如圖2所示。

⑤安裝成水平面的油管，應有(3/1000)～(5/1000)的坡度。管路過長時，每500mm應固定一個夾持油管的管夾。
