朝田油泵RISUNY柱塞泵V18A4R V18B4R V18C4R V18D4R1 2 3液壓泵

淺析液壓系統壓力正常，液壓缸卻不動作的故障原因

液壓系統壓力正常液壓缸卻不動作的故障原因。
液壓系統執行機構運動不正常屬于液壓系統的常見故障之一，而這一故障又有很多情況，系統壓力正常執行元件無動作就是其中之一，小編就來分析一下其中的原因與消除辦法。
　　故障原因1：液壓缸結構上的原因
　　a、活塞端面與缸筒端面緊貼在一起，工作面積不足，故不能啓動;消除方法：端面上要加一條通油槽，使工作液體迅速流向活塞的工作端面。
　　b、具有緩沖裝置的缸筒上單向閥被活塞堵住;消除方法：缸筒的進出油口位置應與活塞端面錯開。
　　故障原因2：活塞桿移動“別勁”
　　a、缸筒與活塞，導向套與活塞桿配合間隙過小;消除方法：檢查配合間隙，并配研到規定值。
　　b、活塞桿與夾布膠木導向套之間的配合過小;消除方法：檢查配合間隙，修刮導向套孔，達到要求的配合間隙。
　　c、 液壓缸裝配不良(如活塞桿、活塞和缸蓋之間同軸度差，液壓缸與工作臺平行度差);消除方法：重新裝配與安裝，不合格零件應更換。
　　故障原因3：液壓回路引起的原因
主要是液壓缸背壓腔油液未與油箱相通，回油路上的調速閥節流口調節過小或連通回油的換向閥未動;消除方法：檢查原因并消除。

臺灣KOMPASS康百世V系列變量柱塞泵
V15A1R10X V15A2R10X V15A3R10X V15A4R10X V15A1L10X V15A2L10X V15A3L10X V15A4L10X
V18A1R10X V18A2R10X V18A3R10X V18A4R10X V18A1L10X V18A2L10X V18A3L10X V18A4L10X
V23A1R10X V23A2R10X V23A3R10X V23A4R10X V23A1L10X V23A2L10X V23A3L10X V23A4L10X
V38A1R10X V38A2R10X V38A3R10X V38A4R10X V38A1L10X V38A2L10X V38A3L10X V38A4L10X
V50A1R10X V50A2R10X V50A3R10X V50A4R10X V50A1L10X V50A2L10X V50A3L10X V50A4L10X
V70A1R10X V70A2R10X V70A3R10X V70A4R10X V70A1L10X V70A2L10X V70A3L10X V70A4L10X

臺灣KOMPASS康百世AR系列變量柱塞泵
AR16-FR01C AR16-FR01B AR16-LR01C AR16-LR01B AR22-FR01C AR22-FR01B AR22-LR01C
AR22-LR01B AR16-FR01CK AR16-FR01BK AR16-LR01CK AR16-LR01BK AR22-FR01CK AR22-LR01CK
AR22-FR01BS AR22-LR01CS AR22-LR01BS AR22-FR01BK AR22-LR01BK AR16-FR01CS AR16-FR01BS
AR16-LR01CS AR16-LR01BS AR22-FR01CS

臺灣KOMPASS康百世定量葉片泵
50T-07-FR 50T-07-LR 50T-12-FR 50T-12-LR 50T-14-FR 50T-14-LR 50T-17-FR 50T-17-LR
50T-20-FR 50T-20-LR 50T-23-FR 50T-23-LR 50T-26-FR 50T-26-LR 50T-30-FR 50T-30-LR
50T-36-FR 50T-36-LR 50T-39-FR 50T-39-LR 150T-48-FR 150T-48-LR 150T-61-FR 150T-61-LR
150T-75-FR 150T-75-LR 150T-94-FR 150T-94-LR 150T-116-FR 150T-116-LR

中高壓變量葉片泵:
VA1-08F-A1 VA1-08F-A2 VA1-08F-A3 VA1-12F-A1 VA1-12F-A2 VA1-12F-A3 VA1-15F-A1 VA1-15F-A2 VA1-15F-A3 VA1-15F-A3
VA1A1-0808F-A1 VA1A1-0808F-A2 VA1A1-0808F-A3 VA1A1-1212F-A1 VA1A1-1212F-A2 VA1A1-1212F-A3 VA1A1-1215F-A1
VA1A1-1215F-A2 VA1A1-1215F-A3
VB1-20F-A1 VB1-20F-A2 VB1-20F-A3 VB1-24F-A1 VB1-24F-A2 VB1-24F-A3
VB1B1-2020F-A1 VB1B1-2020F-A2 VB1B1-2020F-A3 VB1B1-2424F-A1 VB1B1-2424F-A2 VB1B1-2424F-A3
VB3-20F-A1 VB3-20F-A2 VB3-20F-A3 VB3-20F-A4
VC1-26F-A1 VC1-26F-A2 VC1-26F-A3
VD1-25F-A1 VD1-25F-A2 VD1-25F-A3 VD1-30F-A1 VD1-30F-A2 VD1-30F-A3
VD1D1-2525F-A1 VD1D1-2525F-A2 VD1D1-2525F-A3 VD1D1-3030F-A1 VD1D1-3030F-A2 VD1D1-3030F-A3
VD2-20F-A2 VD2-20F-A3 VD2-20F-A4 VD2-25F-A2 VD2-25F-A3 VD2-25F-A4 VD2-30F-A2 VD2-30F-A3 VD2-30F-A4
VD3-25F-A1 VD3-25F-A2 VD3-25F-A3 VD3-25F-A4 VD3-30F-A1 VD3-30F-A2 VD3-30F-A3 VD3-30F-A4
VE1-40F-A1 VE1-40F-A2 VE1-40F-A3 VE1-45F-A1 VE1-45F-A2 VE1-45F-A3
VE1E1-4040F-A1 VE1E1-4040F-A2 VE1E1-4040F-A3 VE1E1-4545F-A1 VE1E1-4545F-A2 VE1E1-4545F-A3
VE2-40F-A2 VE2-40F-A3 VE2-40F-A4
VE3-40F-A1 VE3-40F-A2 VE3-40F-A3 VE3-40F-A4
VF2-54F-A2 VF2-54F-A3 VF2-54F-A4
VF3-54F-A1 VF3-54F-A2 VF3-54F-A3 VF3-54F-A4
VK2-70F-A2 VK2-70F-A3 VK2-70F-A4 VK2-86F-A2 VK2-86F-A3 VK2-86F-A4
VK3-70F-A1 VK3-70F-A2 VK3-70F-A3 VK3-70F-A4 VK3-86F-A1 VK3-86F-A2 VK3-86F-A3 VK3-86F-A4
VQ15-08-FR VQ15-11-FR VQ15-14-FR VQ15-17-FR VQ15-19-FR VQ15-23-FR VQ15-26-FR
VQ15-31-FR VQ25-18-FR VQ25-22-FR VQ25-26-FR VQ25-32-FR VQ25-38-FR VQ25-43-FR
VQ25-52-FR VQ25-60-FR VQ25-65-FR VQ25-75-FR VQ35-60-FR VQ35-66-FR VQ35-76-FR
VQ35-82-FR VQ35-88-FR VQ35-94-FR VQ35-108-FR VQ35-116-FR VQ35-125-FR VQ45-136-FR
VQ45-156-FR VQ45-189-FR VQ45-216-FR VQ45-237-FR VQ215-22-11-FR VQ315-52-23-FR
VQ225-18-26-FR VQ325-108-60-FR VQ425-136-65-FR SVQ215-32-08-FR SVQ435-156-76-FR

高壓變量柱塞泵:
PVS08,PVS16,PVS22,PVS36,PVS46,PVS70,PVS100.
 PVS08-A4-F-R,PVS08-A3-F-R,PVS08-A2-F-R,PVS08-A1-F-R,PVS08-A0-F-R.
 PVS16-A4-F-R,PVS16-A3-F-R,PVS16-A2-F-R,PVS16-A1-F-R,PVS16-A0-F-R.
 PVS22-A4-F-R,PVS22-A3-F-R,PVS22-A2-F-R,PVS22-A1-F-R,PVS22-A0-F-R.
 PVS36-A4-F-R,PVS36-A3-F-R,PVS36-A2-F-R,PVS36-A1-F-R,PVS36-A0-F-R.
 PVS46-A4-F-R,PVS46-A3-F-R,PVS46-A2-F-R,PVS46-A1-F-R,PVS46-A0-F-R.
 PVS70-A4-F-R,PVS70-A3-F-R,PVS70-A2-F-R,PVS70-A1-F-R,PVS70-A0-F-R.
 PVS100-A4-F-R,PVS100-A3-F-R,PVS100-A2-F-R,PVS100-A1-F-R,PVS100-A0-F-R

KOMPASS電磁閥部分型號：
D5-02-2B2B，、D5-02-3C2，、D5-02-3C4，、D4-02-3C4,、D4-03-2B2.
D5-02-3C2,D5-02-2B2,D5-02-3,D5-02-3C60,D5-02-2D2,
D5-03-3C2,D5-03-2B2,D5-03-3,D5-03-3C60,D5-03-2D2.
D4-02-3C2,D4-02-2B2,D4-02-3,D4-02-3C60,D4-02-2D2,
D4-03-3C2,D4-03-2B2,D4-03-3,D4-03-3C60,D4-03-2D2.
D5-02-2B2B D5-02-2B3B D5-02-2B4B D5-02-2B5B D5-02-2B40B D5-02-2B60B
D5-02-2B2-A25 D5-02-2B2-A15 D5-02-2B2-A35 D5-02-2B2-D1 D5-02-2B2-D2
D5-02-2B3-A25 D5-02-2B3-A15 D5-02-2B3-A35 D5-02-2B3-D1 D5-02-2B3-D2
D5-02-2B8-A25 D5-02-2B8-A15 D5-02-2B8-A35 D5-02-2B8-D1 D5-02-2B8-D2

臺灣KOMPASS液控單向閥
MPA-04B 、MPA-03A   、MPA-03B  、MPA-03C、MPA-04A   、MPA-04B  、MPA-04C、MPA-06A   、MPA-06B  、MPA-06A、

臺灣KOMPASS減壓閥：
MRP-02A-H 、MRP-02B-H 、MRP-02C-H 、MRP-02H-H、MRP-03-A-H 、MRP-03-B-H 、MRP-03-C-H 、MRP-03-H-H、、MRB-06-A-H 、MRB-06-B-H 、MRRP-02-B-M MRRP-03-B-M MRRP-02-B-H MRRP-03-B-H MRRP-02-C-M MRRP-03-C-M
MRRP-02-C-H MRRP-03-C-H MRRP-02-H-M MRRP-03-H-M MRRP-02-H-H MRRP-03-H-H
MRRA-02-B-M MRRA-03-B-M MRRA-02-B-H MRRA-03-B-H MRRA-02-C-M MRRA-03-C-M
MRRA-02-C-H MRRA-03-C-H MRRA-02-H-M MRRA-03-H-M MRRA-02-H-H MRRA-03-H-H
MRRB-02-B-M MRRB-03-B-M MRRB-02-B-H MRRB-03-B-H MRRB-02-C-M MRRB-03-C-M
MRRB-02-C-H MRRB-03-C-H MRRB-02-H-M MRRB-03-H-M MRRB-02-H-H MRRB-03-H-H
MQP-02-B MQP-02-C MQP-02-H MQP-03-BMQP-03-C MQP-03-HMQP-02-B-P MQP-02-C-P
MQP-02-H-P MQP-03-B-P MQP-03-C-P MQP-03-H-P MHB-06-B MHB-06-H
MHB-06-B-P MHB-06-H-P MHB-04-B-P MHB-04-H-P MHB-04-B MHB-04-H
MHA-02-B MHA-03-B MHA-02-H MHA-03-H MHB-02-B MHB-03-B MHB-02-H MHB-03-H
MHB-04-B MHB-04-H MHA-02-B-P MHA-03-B-P MHA-02-H-P MHA-03-H-P
MHB-02-B-P MHB-03-B-P MHB-02-H-P MHB-03-H-P MTP-02 MTP-03MTT-02 MTT-03
MSP-02 MSP-03  MSA-02-X MSA-03-X MSA-04-X MSA-06-X MSA-02-Y MSA-03-Y
MSA-04-Y MSA-06-Y MSB-02-X MSB-03-X MSB-04-X MSB-06-X MSB-02-Y MSB-03-Y
MSB-04-Y MSB-06-Y MSW-02-X MSW-03-X MSW-04-X MSW-06-X MSW-02-Y MSW-03-Y
MRB-03-A-H 、MRB-03-B-H 、MRB-03-C-H 、MRB-03-H-H、

手動換向閥
DMT-03-W-2B2 DMT-04-W-2B2 DMT-06-W-2B2 DMT-10-W-2B2 DMG-02-W-2B2 DMG-03-W-2B2
DMT-03-W-3C2 DMT-04-W-3C2 DMT-06-W-3C2 DMT-10-W-3C2 DMG-02-W-3C2 DMG-03-W-3C2
DMT-03-W-3C3 DMT-04-W-3C3 DMT-06-W-3C3 DMT-10-W-3C3 DMG-02-W-3C3 DMG-03-W-3C3
DMT-03-W-3C4 DMT-04-W-3C4 DMT-06-W-3C4 DMT-10-W-3C4 DMG-02-W-3C4 DMG-03-W-3C4
DMT-03-W-3C6 DMT-04-W-3C6 DMT-06-W-3C6 DMT-10-W-3C6 DMG-02-W-3C6 DMG-03-W-3C6

疊加式單向閥
MCP-02-B MCP-03-B MCP-04-B MCP-06-B MCA-02-B MCA-03-B MCB-02-B MCB-03-B
MCT-02-B MCT-03-B MCT-04-B MCT-06-B MCW-02-B MCW-03-B MCW-03-B MCW-02-B

疊加式液控單向閥
MPW-02-B MPW-03-B MPW-04-B MPW-06-B MPDA-03-B MPDB-03-B MPDW-03-B
MPA-02-B MPA-03-B MPA-04-B MPA-06-B MPB-02-B MPB-03-B MPB-04-B MPB-06-B
MBP-01-B-H MBP-02-B-H MBP-03-B-H MBP-06-B-H MBP-01-B-M MBP-02-B-M
MBP-03-B-M MBP-06-B-M MBA-01-B-H MBA-02-B-H MBA-03-B-H MBA-06-B-H
MBA-01-B-M MBA-02-B-M MBA-03-B-M MBA-06-B-M MBB-01-B-H MBB-02-B-H
MBB-03-B-H MBB-06-B-H MBB-01-B-M MBB-02-B-M MBB-03-B-M MBB-06-B-M
MBW-01-B-H MBW-02-B-H MBW-03-B-H MBW-01-B-M MBW-02-B-M MBW-03-B-M
MBP-01-C-H MBP-02-C-H MBP-03-C-H MBP-06-C-H MBP-01-C-M MBP-02-C-M
MBP-03-C-M MBP-06-C-M MBA-01-C-H MBA-02-C-H MBA-03-C-H MBA-06-C-H
MBA-01-C-M MBA-02-C-M MBA-03-C-M MBA-06-C-M MBB-01-C-H MBB-02-C-H
MBB-03-C-H MBB-06-C-H MBB-01-C-M MBB-02-C-M MBB-03-C-M MBB-06-C-M
MBW-01-C-H MBW-02-C-H MBW-03-C-H MBW-01-C-M MBW-02-C-M MBW-03-C-M
MBP-01-H-H MBP-02-H-H MBP-03-H-H MBP-06-H-H MBP-01-H-M MBP-02-H-M
MBP-03-H-M MBP-06-H-M MBA-01-H-H MBA-02-H-H MBA-03-H-H MBA-06-H-H
MBA-01-H-M MBA-02-H-M MBA-03-H-M MBA-06-H-M MBB-01-H-H MBB-02-H-H

VOP潤滑泵
VOP-203-A2-F-RV VOP-204-A2-F-RV VOP-206-A2-F-RV VOP-208-A2-F-RV VOP-210-A2-F-RV
VOP-212-A2-F-RV VOP-216-A2-F-RV VOP-220-A2-F-RV
VOP-203-A1-F-RV VOP-204-A1-F-RV VOP-206-A1-F-RV VOP-208-A1-F-RV VOP-210-A1-F-RV
VOP-212-A1-F-RV VOP-216-A1-F-RV VOP-220-A1-F-RV VOP-203-A2-F-RV VOP-204-A2-F-RV
VOP-206-A2-F-RV VOP-208-A2-F-RV VOP-210-A2-F-RV VOP-212-A2-F-RV VOP-216-A2-F-RV
VOP-220-A2-F-RVVOP-203-A3-F-RV VOP-204-A3-F-RV VOP-206-A3-F-RV VOP-208-A3-F-RV
VOP-210-A3-F-RVVOP-212-A3-F-RV VOP-216-A3-F-RV VOP-220-A3-F-RV
